- Waveshare ESP32-S3 Mini Dev Board, Based on ESP32-S3FH4R2 Dual-Core, 240MHz, 2.4GHz Wi-Fi & Bluetooth 5 (w/ Headers)
- Offers dual-core 240MHz processor
- Supports Wi-Fi 2.4GHz and Bluetooth 5
- Includes 24 multifunction GPIO pins
- Features USB Type-C and WS2812 RGB LED
- Provides comprehensive SDK resources
The Waveshare ESP32-S3 Mini Dev Board, Based on ESP32-S3FH4R2 Dual-Core, 240MHz, 2.4GHz Wi-Fi & Bluetooth 5 (w/ Headers) is a versatile development platform featuring a dual-core processor with a 240MHz frequency. It supports 2.4GHz Wi-Fi and Bluetooth 5, making it suitable for a wide range of wireless applications. The board includes multi-function GPIO pins and is designed for SMD applications with a castellated module and onboard ceramic antenna. It integrates a USB serial port controller and supports various interfaces, providing flexibility for developers. Comprehensive SDK and development resources are available to facilitate project initiation.
- 1x Waveshare ESP32-S3 Mini Dev Board, Based on ESP32-S3FH4R2 Dual-Core, 240MHz, 2.4GHz Wi-Fi & Bluetooth 5 (w/ Headers)
- Equipped with Xtensa® 32-bit LX7 dual-core processor, up to 240MHz main frequency
- Supports 2.4GHz Wi-Fi (802.11 b/g/n) and Bluetooth® 5 (LE)
- Built-in 512KB of SRAM and 384KB ROM, onboard 4MB Flash memory, and 2MB PSRAM
- Castellated module and onboard ceramic antenna for direct soldering to carrier boards
- Supports flexible clock and independent module power supply settings for low power consumption
- Integrated USB serial port full-speed controller
- 24 × GPIO pins for flexible pin function configuration
- Includes 4 × SPI, 2 × I2C, 3 × UART, 2 × I2S, 2 × ADC
- USB Type-C Port
- ME6217C33M5G low dropout LDO, 800mA (Max)
- WS2812 RGB LED
- 2.4G ceramic antenna
- BOOT button
- RESET button
