Description
- Actuonix PQ12-S Linear Actuator w/ Limit Switches 63:1 6 Volts
- Revolutionize designs with compact linear actuator
- Empower precise control with position feedback
- Facilitate automation with end-of-stroke limit switches
- Operate easily using reversible DC voltage
- Maximize performance with diverse speed and force options
The Actuonix PQ12-S Linear Actuator w/ Limit Switches 63:1 6 Volts represents a groundbreaking advancement in miniature linear actuators, enabling innovative motion-enabled product designs. This compact actuator serves as an excellent alternative to custom push/pull mechanisms, appealing to both hobbyists and OEM designers due to its affordability and accessibility.
PQ12 actuators are fully integrated linear motion devices that offer position feedback for precise control or end-of-stroke limit switches for straightforward two-position automation. Operation is simplified by applying a DC voltage to extend the actuator and reversing the polarity to retract it. Various gear ratios and voltage options are available, providing diverse speed and force configurations.
- 1x Actuonix PQ12-S Linear Actuator w/ Limit Switches 63:1 6 Volts
- 2x Mounting bracket
- 1x M3 mounting hardware
- 1x FPC ribbon cable connector
- Stroke Length (mm): 20
- Closed Hole to Hole (mm): 42
- Weight (grams): 21
ZIP File
- Actuonix PQ12-S Linear Actuator w/ Limit Switches 63:1 6 Volts – PQ12 3D Model
PDF File
- Actuonix PQ12 – Datasheet
- Backdrive Force: 25 N
- Control: S
- Gear Ratio: 63
- Life: Standard
- Maximum Load: 45 N
- Model: PQ12
- No Load Speed: 28 mm/s
- Peak Efficiency Load: 12 N
- Voltage: 6 VDC
