- DOBOT CR12A 6-Axis Collaborative Robot Arm (12kg / 1200mm)
- Integrated EtherCAT servo bus for ultra-fast, synchronized motion control
- Laser-calibrated for absolute positioning accuracy under 0.4 mm
- PLCd Cat.3 safety controller with 20+ built-in safety features
- Electromagnetic brake engages in under 18 ms for drop protection
- 24 DI/DO ports with support for TCP/IP, Modbus, EtherNet/IP, EtherCAT, and PROFINET
- Compatible with DobotStudio Pro (graphical programming, SDKs, ROS support)
- Designed for medium-to-heavy tasks like material handling and gluing
The DOBOT CR12A 6-Axis Collaborative Robot Arm (12kg / 1200mm) is a powerful mid-to-heavy-duty collaborative robot designed for applications requiring balance between reach, precision, and payload. With a working radius of 1200mm and up to 12kg lift, it’s suitable for diverse industries including automotive, consumer electronics, and logistics.
The CR12A has a working radius of 1200 mm and a maximum payload of 12 kg. With advanced motion control algorithm, the CR12A operates more stably, with residual vibrations reduced by 50% during high-speed emergency stops.
Its advanced control and safety features are shared across the CR-A platform, allowing seamless scaling from smaller models while maintaining identical software and integration protocols
- DOBOT CR12A 6-axis collaborative robot arm
- DOBOT robot controller
- 5m power and signal cable set
- Quick start documentation
- Arm reach: 1200 mm
- Robot weight: 39.5 kg
Training materials and curriculum are available after purchase. Please contact us for details.
docReady(function() {$(‘button[aria-controls=unique-tab-5]’).one(‘click’,function() {$(“#iframe-video-1″).html(”);})});
| DOBOT CR12A Specifications | |
|---|---|
| Weight | 39.5 kg |
| Maximum Payload | 12 kg |
| Working Radius | 1200 mm |
| Maximum Linear Speed | 2 m/s |
| Maximum Joint Speed | |
| J1 / J2 | 150 °/s |
| J3 | 180 °/s |
| J4 / J5 / J6 | 223 °/s |
| Range of Motion | |
| J1/J2/J4/J5/J6 | ±360° |
| J3 | ±160° |
| I/O Ports | 2x AI, 2x DO, 2x DI (Multiplexed with RS485) |
| Ports | |
| Repeatability | ±0.03 mm |
| IP Rating / Noise | IP54 / ≤ 70 dB |
| Working Environment | 0 ~ 50 °C |
| Power | 350W |
| Installation Orientation | Any Angle |
| Cable Length to Controller | 5 m |
| Materials | Aluminum alloy, ABS plastic |
